Quick Overview Bilstein XVA Series shock absorbers features aluminum threaded body construction designed for motorsports applications. The large volume dual zone nitrogen bulb, with optional base valve (sold separately), allows for lower gas pressure for increased grip. These shock absorbers are available in non-, single and double adjustable configurations for precise on-vehicle tuning options. Pistons, piston bands and heims are sold separately to allow the greatest flexibility in upgrade combinations. XVA Series shock absorbers are ideal for racers looking for an aluminum, rebuildable design with multiple upgrade options and superior performance.

Attributes:

• GTIN: 00651860873992
• Brand Name: Bilstein
• Extended Length (MM): 652.5
• Finish: Clear Anodized
• Lower Mount Type: Sold Separately
• Collapsed Length (MM): 416.0
• Body Material: Aluminum
• Valving Identifier: Dry Kit (no valving)
• Piston Type: Sold Separately
• Series: XVA Series
• Internal Design: Monotube
• Body Design: Threaded Body Large Bulb Screw Top (Coilover)
• Collapsed Length (IN): 16.38
• Spring Seat Included: No
• Body Diameter (ID): 46mm
• Upper Mount Type: Sold Separately
• Extended Length (IN): 25.69
• Adjustable Damping: Non-Adjustable
• Boot Included: No

Extended Information:

• Country of Origin: United States
• Emissions : Released
• Life Cycle Status: Available To Order

Packing Information:

• Quantity of Each: 1.0
• Package UOM: EA
• Dimension: 26.8000 x 2.9500 x 2.9500 inches
• Weight: 3.2000 lb
